部署满血DeepSeek R1的避坑指南-vLLM 0.7.1

今天看到vLLM的朋友圈发布了DeepSeek R1的PP支持，立刻开始我的捣鼓之旅，假如我训练的超大MoE上线了，也得做好技术准备工作是不嘛。把踩坑经验给大家分享一下，希望能够相比于官方文档更白话一点。知乎@游凯超说一定要让整个过程变得丝滑无比，我俩配合做了几个验证，现在应该只需要 Step0 和 Step3 就可以run起来了，如果遇到autoscalar的相关问题可以看Step1可以解决。

m0_63171455

3936人浏览 · 2025-02-05 21:13:35

m0_63171455 · 2025-02-05 21:13:35 发布

今天看到vLLM的朋友圈发布了DeepSeek R1的PP支持，立刻开始我的捣鼓之旅，假如我训练的超大MoE上线了，也得做好技术准备工作是不嘛。把踩坑经验给大家分享一下，希望能够相比于官方文档更白话一点。

Distributed Inference and Serving: https://docs.vllm.ai/en/latest/serving/distributed_serving.html#running-vllm-on-multiple-nodes

知乎@游凯超说一定要让整个过程变得丝滑无比，我俩配合做了几个验证，现在应该只需要 Step0 和 Step3 就可以run起来了，如果遇到autoscalar的相关问题可以看Step1可以解决。

Step 0 Prepare weights & Environment

由于权重太大了，即使你网速可以，也不建议直连下载了。大家可以先从HF及或代理弄一份权重回来，直连大概率直接超时或者把公网IP打爆。我们今天展示的多机多卡8xH20 (x2) 部署，对应TP size 8，PP size 2，所以要搞两台这样的机器过来。同时有一个假设：两机的网络互通，不一定需要IB，储存需要共享（NAS或OSS均可），完成准备工作之后便可以做第一步。

Step 1 Setup up Ray & Cluster

官方文档里面简单带过了这一部分，但这个是我被卡时间太久的问题。首先我说一下官方文档的意思，就是让你准备好两个节点，之间用ray start这个CLI去建立好ray集群。因为后面要用，但是比较坑的有两点，第一点是启动的命令似乎有点点问题，我在前几次尝试的时候都遇到了Ray的autoscaler报错的问题：

`(autoscaler +1m19s) Error: No available node types can fulfill resource request {'node:33.18.26.153': 0.001, 'GPU': 1.0}. Add suitable node types to this cluster to resolve this issue.   (autoscaler +1m54s) Error: No available node types can fulfill resource request {'GPU': 1.0, 'node:33.18.26.153': 0.001}. Add suitable node types to this cluster to resolve this issue.   (autoscaler +2m29s) Error: No available node types can fulfill resource request {'GPU': 1.0, 'node:33.18.26.153': 0.001}. Add suitable node types to this cluster to resolve this issue.   INFO 02-02 09:39:14 ray_utils.py:212] Waiting for creating a placement group of specs for 150 seconds. specs=[{'node:33.18.26.153': 0.001, 'GPU': 1.0}, {'GPU': 1.0}, {'GPU': 1.0}, {'GPU': 1.0}, {'GPU': 1.0}, {'GPU': 1.0}, {'GPU': 1.0}, {'GPU': 1.0}, {'GPU': 1.0}, {'GPU': 1.0}, {'GPU': 1.0}, {'GPU': 1.0}, {'GPU': 1.0}, {'GPU': 1.0}, {'GPU': 1.0}, {'GPU': 1.0}]. Check `ray status` to see if you have enough resources.   `

这看起来就很奇怪，因为vLLM找Ray集群要的Resource是custom resource，‘node:33.18.26.153’:0.001，这可以理解成vLLM优先要driver节点。但是这个东西我印象中是需要启动ray的时候自己设置的：

https://docs.ray.io/en/latest/ray-core/scheduling/resources.html#custom-resources

像这样才会有这种resource。背后的原因是对于多（虚拟）网卡的机器会有多个网段，vLLM assume使用POD IP来做Ray的master寻址。

解法1：设置 VLLM_HOST_IP

# Get local IP address and set on every node before Ray start   VLLM_HOST_IP=$(hostname -I | awk '{print $1}')   export VLLM_HOST_IP

解法2：魔改Ray启动逻辑

def get_actual_ip():       """Get the actual IP address of the current machine."""       try:           # Create a socket to connect to an external server (doesn't actually connect)           s = socket.socket(socket.AF_INET, socket.SOCK_DGRAM)           s.connect(('8.8.8.8', 80))           ip = s.getsockname()[0]           s.close()           return ip       except Exception:           # Fallback to hostname-based IP resolution           return socket.gethostbyname(socket.gethostname())      def start_ray_cluster():       free_ports = get_free_ports()       port = free_ports[0]       node_manager_port = free_ports[1]       master_addr = get_master_addr()       rank = get_rank()       node_ip = get_actual_ip()  # Use the new function to get actual IP              # Define custom resource based on node IP       resource_spec = f'--resources=\'{{"node:{node_ip}": 1}}\''              if rank == 0:           cmd = f"ray start --head --port={port} --node-ip-address={master_addr} --node-manager-port {node_manager_port} --node-name={master_addr} {resource_spec}"       else:           cmd = f"ray start --address={master_addr}:{port} --node-manager-port {node_manager_port} --node-name={get_addr()} {resource_spec}"              if ray.is_initialized():           print("Ray is already initialized, skipping node level init.")       else:           stop_cmd = "ray stop"           execute(stop_cmd, check=True)           print(f"Executing Ray start command: {cmd}")           execute(cmd, check=True)

其中execute可以这样写，

import time   import subprocess      def execute(cmd, check=False, retry=1):       ret = subprocess.run(cmd, shell=True, capture_output=True, text=True, check=check)       state = ret.returncode == 0       msg = ret.stdout if state else ret.stderr       if not state and retry > 1:           print(f"execute {cmd} got error {msg}, retry...")           time.sleep(1)           return execute(cmd, check, retry-1)       return state, msg

然后这里我稍微提一下ray的一些基础玩法：大家在使用Ray的时候一般都不是在裸机上面的，大部分深度学习的资源都是k8s结合kubeflow或者volcano这样的插件分发出来的。环境变量里面会有当前是第几个rank，头结点master_addr这样的信息，大家可以根据自己的需要把这些函数实现一下。比较坑的 {resource_spec} 这里我已经替大家把坑给填了。

Step 2 Other small bugs

期间又报了两个错误，花了一点时间修复：

Traceback (most recent call last):     File "/usr/local/bin/vllm", line 5, in <module>       from vllm.scripts import main     File "/usr/local/lib/python3.10/dist-packages/vllm/__init__.py", line 4, in <module>       from vllm.engine.async_llm_engine import AsyncLLMEngine     File "/usr/local/lib/python3.10/dist-packages/vllm/engine/async_llm_engine.py", line 15, in <module>       from vllm.engine.llm_engine import (DecoderPromptComponents, LLMEngine,     File "/usr/local/lib/python3.10/dist-packages/vllm/engine/llm_engine.py", line 24, in <module>       from vllm.engine.output_processor.interfaces import (     File "/usr/local/lib/python3.10/dist-packages/vllm/engine/output_processor/interfaces.py", line 6, in <module>       from vllm.engine.output_processor.stop_checker import StopChecker     File "/usr/local/lib/python3.10/dist-packages/vllm/engine/output_processor/stop_checker.py", line 6, in <module>       from vllm.transformers_utils.tokenizer import AnyTokenizer     File "/usr/local/lib/python3.10/dist-packages/vllm/transformers_utils/tokenizer.py", line 13, in <module>       from vllm.transformers_utils.tokenizers import (BaichuanTokenizer,     File "/usr/local/lib/python3.10/dist-packages/vllm/transformers_utils/tokenizers/__init__.py", line 2, in <module>       from vllm.transformers_utils.tokenizers.mistral import MistralTokenizer     File "/usr/local/lib/python3.10/dist-packages/vllm/transformers_utils/tokenizers/mistral.py", line 9, in <module>       from mistral_common.tokens.tokenizers.mistral import ChatCompletionRequest     File "/usr/local/lib/python3.10/dist-packages/mistral_common/tokens/tokenizers/mistral.py", line 32, in <module>       from mistral_common.tokens.tokenizers.multimodal import (     File "/usr/local/lib/python3.10/dist-packages/mistral_common/tokens/tokenizers/multimodal.py", line 6, in <module>       import cv2     File "/usr/local/lib/python3.10/dist-packages/cv2/__init__.py", line 181, in <module>       bootstrap()     File "/usr/local/lib/python3.10/dist-packages/cv2/__init__.py", line 175, in bootstrap       if __load_extra_py_code_for_module("cv2", submodule, DEBUG):     File "/usr/local/lib/python3.10/dist-packages/cv2/__init__.py", line 28, in __load_extra_py_code_for_module       py_module = importlib.import_module(module_name)     File "/usr/lib/python3.10/importlib/__init__.py", line 126, in import_module       return _bootstrap._gcd_import(name[level:], package, level)     File "/usr/local/lib/python3.10/dist-packages/cv2/typing/__init__.py", line 171, in <module>       LayerId = cv2.dnn.DictValue   AttributeError: module 'cv2.dnn' has no attribute 'DictValue'

一个opencv封建余孽的问题，pin住opencv的版本来解决

pip install opencv-python-headless==4.5.4.58

还有一个load之后报TypeError的问题

[rank0]:   File "/usr/local/lib/python3.10/dist-packages/vllm/model_executor/models/deepseek_v3.py", line 472, in forward   [rank0]:     kv_c, k_pe = self.kv_a_proj_with_mqa(hidden_states)[0].split(   [rank0]:   File "/usr/local/lib/python3.10/dist-packages/torch/nn/modules/module.py", line 1736, in _wrapped_call_impl   [rank0]:     return self._call_impl(*args, **kwargs)   [rank0]:   File "/usr/local/lib/python3.10/dist-packages/torch/nn/modules/module.py", line 1747, in _call_impl   [rank0]:     return forward_call(*args, **kwargs)   [rank0]:   File "/usr/local/lib/python3.10/dist-packages/vllm/model_executor/layers/linear.py", line 246, in forward   [rank0]:     output = self.quant_method.apply(self, x, bias)   [rank0]:   File "/usr/local/lib/python3.10/dist-packages/vllm/model_executor/layers/quantization/fp8.py", line 357, in apply   [rank0]:     return apply_w8a8_block_fp8_linear(   [rank0]:   File "/usr/local/lib/python3.10/dist-packages/vllm/model_executor/layers/quantization/utils/fp8_utils.py", line 61, in apply_w8a8_block_fp8_linear   [rank0]:     output = w8a8_block_fp8_matmul(q_input,   [rank0]:   File "/usr/local/lib/python3.10/dist-packages/vllm/model_executor/layers/quantization/utils/fp8_utils.py", line 470, in w8a8_block_fp8_matmul   [rank0]:     configs = get_w8a8_block_fp8_configs(N, K, block_size[0], block_size[1])   [rank0]:   File "/usr/local/lib/python3.10/dist-packages/vllm/model_executor/layers/quantization/utils/fp8_utils.py", line 407, in get_w8a8_block_fp8_configs   [rank0]:     device_name = current_platform.get_device_name().replace(" ", "_")   [rank0]: TypeError: a bytes-like object is required, not 'str'

通过升级 pynvml 解决

pip install pynvml -U

Step 3 Run the model

这一步反而是最简单的：

vllm serve /your/path/to_checkpoint_deepseek-r1/ --tensor-parallel-size 8 --pipeline-parallel-size 2 --trust-remote-code --host 0.0.0.0

由于有了PP加持，没有IB的同学也可以尝试把sequence length和bsz给稍微拉大一些拉。用gaoce哥哥贡献的Reasoning Output，在同一台机器来试一把，或者换一台机器把localhost改了：

from openai import OpenAI      # Modify OpenAI's API key and API base to use vLLM's API server.   openai_api_key = "EMPTY"   openai_api_base = "http://localhost:8000/v1"      client = OpenAI(       api_key=openai_api_key,       base_url=openai_api_base,   )      models = client.models.list()   model = models.data[0].id      # Round 1   messages = [{"role": "user", "content": "9.11 and 9.8, which is greater?"}]   response = client.chat.completions.create(model=model, messages=messages)      reasoning_content = response.choices[0].message.reasoning_content   content = response.choices[0].message.content      print("reasoning_content:", reasoning_content)   print("content:", content)

对，你不是卡主了，是你的钱包不够厚。切到后台可以看到，这个prompt里面

INFO 02-02 14:18:52 metrics.py:453] Avg prompt throughput: 1.7 tokens/s, Avg generation throughput: 0.1 tokens/s, Running: 1 reqs, Swapped: 0 reqs, Pending: 0 reqs, GPU KV cache usage: 0.0%, CPU KV cache usage: 0.0%.   INFO 02-02 14:18:57 metrics.py:453] Avg prompt throughput: 0.0 tokens/s, Avg generation throughput: 20.7 tokens/s, Running: 1 reqs, Swapped: 0 reqs, Pending: 0 reqs, GPU KV cacheusage: 0.0%, CPU KV cache usage: 0.0%.   INFO 02-02 14:19:02 metrics.py:453] Avg prompt throughput: 0.0 tokens/s, Avg generation throughput: 20.5 tokens/s, Running: 1 reqs, Swapped: 0 reqs, Pending: 0 reqs, GPU KV cacheusage: 0.0%, CPU KV cache usage: 0.0%.   INFO 02-02 14:19:07 metrics.py:453] Avg prompt throughput: 0.0 tokens/s, Avg generation throughput: 20.5 tokens/s, Running: 1 reqs, Swapped: 0 reqs, Pending: 0 reqs, GPU KV cacheusage: 0.0%, CPU KV cache usage: 0.0%.   INFO 02-02 14:19:12 metrics.py:453] Avg prompt throughput: 0.0 tokens/s, Avg generation throughput: 20.1 tokens/s, Running: 1 reqs, Swapped: 0 reqs, Pending: 0 reqs, GPU KV cacheusage: 0.0%, CPU KV cache usage: 0.0%.   INFO 02-02 14:19:17 metrics.py:453] Avg prompt throughput: 0.0 tokens/s, Avg generation throughput: 19.8 tokens/s, Running: 1 reqs, Swapped: 0 reqs, Pending: 0 reqs, GPU KV cacheusage: 0.1%, CPU KV cache usage: 0.0%.   INFO 02-02 14:19:22 metrics.py:453] Avg prompt throughput: 0.0 tokens/s, Avg generation throughput: 19.4 tokens/s, Running: 1 reqs, Swapped: 0 reqs, Pending: 0 reqs, GPU KV cacheusage: 0.1%, CPU KV cache usage: 0.0%.   INFO 02-02 14:19:27 metrics.py:453] Avg prompt throughput: 0.0 tokens/s, Avg generation throughput: 19.1 tokens/s, Running: 1 reqs, Swapped: 0 reqs, Pending: 0 reqs, GPU KV cacheusage: 0.1%, CPU KV cache usage: 0.0%.

稍等一会他就会告诉你9.8更大了。

祝大家捣鼓顺利，感谢vLLM社区的工作。

https://github.com/vllm-project/vllm/pull/12679
